.085 in. (2.16mm)
Density
Accessories
Miniature Ribbon
The following accessories are available to make your application using Cinch Miniature Ribbon and SUPERIBBON prod-
ucts as complete and cost-effective as possible.
Dust Covers for all Metal Shell and All-Plastic Miniature Ribbon Connectors
Dust covers may be added to Miniature Ribbon or SUPERIBBON assemblies to protect
the mating area from damage or contamination when the connector is left unmated. They
can be useful for protection from handling damage during assembly, or can be left on the
connector for protection of unused system I/O ports.
Compliant-pin Miniature Ribbon products come with special seating fixtures that must be
used to install the connectors onto the printed circuit board. These may be replaced after
insertion; however, with standard dust covers to maintain the standard color code, if so
desired. Material: UL94V-0 rated polyethelene (blue for plug covers; red for socket covers)
Ordering Information, Dust Covers
Size
14
24
36
50
64
Plug Cover
57-1001
57-1003
57-1005
57-1008
57-1009
Socket Cover
57-1002
57-1004
57-1006
57-1022
57-1010
Bent Bail Latch for End-Entry Applications
Standard Bail Latches will not lock under a plug cable in a typical end-entry
application. This latch, which is bent at a 90° angle, may be used to
replace a standard latch in this situation.
Material: Stainless Steel
Ordering Information, Bent Bail Latch
Part No. 57-BL-90
Mounting Screws and Related Hardware
Many Cinch Miniature Ribbon and SUPERIBBON products include all the hardware required for the most common appli-
cation for the product; however, these alternatives may be desirable to better fit product to a specific use.
Part No.
Description
Typical Applications
4-40UNC2AX11/32
#4-40 x .343 Pan Head Screw
?
?
SUPERIBBON to mate with female screwlock
PC Mount connector to PCB (secured from rear)
4-40UNC2AX17/32
4-40UNC2AX5/8
4-40UNC2AX3/4
#4-40 x .525 Pan Head Screw
#4-40 x .625 Fillister Head Screw
#4-40 x .750 Pan Head Screw
?
?
?
SUPERIBBON to threaded panel
Metal Shell Running Cable (included on
standard end-entry metal shell products)
SUPERIBBON Running Cable (included on
6
standard end-entry SUPERIBBON products)
?
SUPERIBBON to front-panel mounted
SUPERIBBON held by panel clips
4-40UNC2AX7/8
4-40X1/4SPCR
#4-40 x .875
Hex Spacer, #4-40 Internal Thread x .250
?
?
Miscellaneous
Female Screwlock
6-51
Call Toll Free: 1 (800) 323-9612
